Characteristics

1=>Measuring range reaches to 3000μm.

2=>Large sample pool designed with Anti-particle aggregation and deposition

3=>Automatic operation includes auto-judgement of optical path deviation and sample window contamination.

4=>Adjustable revolving speed, maximum to 5000 RPM.

5=>Intelligent software provides data analysis: differential distribution, cumulative distribution, standard classification, volume distribution, area distribution, quantity distribution, R-R distribution, custom classification, and item classification, with functions such as averaging, statistics, comparison, and pattern transformation.

6=>Test report: there are particle size distribution curves, detailed particle size data tables and user-defined summary tables, and there are D3, D10, D50, D90, D97, D (1,0), D (3,2), D (4,3), span, peak particle size, specific surface area and other characteristic parameters, and there are multiple user-defined parameters that can be inputted as required; The weight specific surface area and volume specific surface area can be interchanged; It can save the granularity distribution graph and granularity data chart as pictures, and supports PDF, WORD and EXCEL report templates.

Specifications
